Welcome to Maduka Metals, your trusted partner for premium industrial materials right here in Abuja. We take pride in supplying businesses across Nigeria with high-quality Copper C10100 bars and rods, ensuring you have access to the very best for your critical projects. Our commitment is to provide not just products, but reliable solutions backed by local expertise and a dedication to supporting the growth of our nation’s industries with dependable, top-tier copper.
This particular copper, known as C10100 or Oxygen-Free Electronic (OFE) copper, is renowned for its exceptional purity, exceeding 99.99%. This composition gives it outstanding electrical and thermal conductivity, making it one of the most efficient materials for transferring energy and heat. Mechanically, it offers excellent ductility and formability, allowing it to be easily shaped and worked without losing its inherent strength, which is crucial for precision manufacturing.
| Specifications | ASTM B187, ASTM B301 / ASME SB187, SB301 |
| Range | 3.17 MM TO 350 MM DIA |
| Form | Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc. |
| Copper Grades | C10100 |
| Size in mm | Size in inch |
|---|---|
| .0938 | 3/32 |
| .125 | 1/8 |
| .1875 | 3/16 |
| .250 | 1/4 |
| .2813 | 9/32 |
| .3125 | 5/16 |
| .375 | 3/8 |
| .4375 | 7/16 |
| .500 | 1/2 |
| .5625 | 9/16 |
| .625 | 5/8 |
| .6875 | 11/16 |
| .750 | 3/4 |
| .8125 | 13/16 |
| .875 | 7/8 |
| .9375 | 15/16 |
| 1 | 1 |
| 1.0625 | 1-1/16 |
| 1.125 | 1-1/8 |
| 1.1875 | 1-3/16 |
| 1.250 | 1-1/4 |
| 1.3125 | 1-5/16 |
| 1.375 | 1-3/8 |
| 1.500 | 1-1/2 |
| 1.625 | 1-5/8 |
| 1.750 | 1-3/4 |
| 1.8125 | 1-13/16 |
| 1.875 | 1-7/8 |
| 2 | 2 |
| 2.250 | 2-1/4 |
| 2.500 | 2-1/2 |
| 2.625 | 2-5/8 |
| 2.750 | 2-3/4 |
| 3 | 3 |
| 3.250 | 3-1/4 |
| 3.500 | 3-1/2 |
| 4 | 4 |
| 4.500 | 4-1/2 |
| 5 | 5 |
| 6 | 6 |
| Diameter of round bar in milimeter | Kilogram/meter |
|---|---|
| 3 | .064 |
| 5 | .179 |
| 6 | .257 |
| 8 | .448 |
| 10 | .715 |
| 12 | 1.029 |
| 15 | 1.575 |
| 16 | 1.78 |
| 20 | 2.79 |
| 25 | 4.375 |
| 28 | 5.48 |
| 30 | 6.27 |
| 35 | 8.575 |
| 40 | 11.2 |
| 45 | 14.175 |
| 50 | 17.46 |
| Grade | Sn | Sb | Bi | Zn | Pb | P | Ni | As | Fe | S | O |
|---|---|---|---|---|---|---|---|---|---|---|---|
| UNS C10100 | .002 | .002 | .001 | .003 | .003 | .002 | .002 | .002 | .004 | .004 | .002 |
Yes, Copper C10100 Bars and Rods are fully recyclable. Copper retains its properties after recycling, making it an environmentally friendly material for sustainable industrial use.
Yes, Copper C10100 Bars and Rods can be used for natural gas applications due to their excellent corrosion resistance and suitability for non-aggressive gas environments, ensuring reliable performance.
Common grades of copper used in bars and rods manufacturing include C10100 (oxygen-free copper), C11000 (electrical copper), and C10200 (semi-oxygen-free copper), each offering varying conductivity and corrosion resistance.
The uses for these high-purity bars and rods are extensive, forming the backbone of many advanced industries. They are essential for manufacturing sophisticated electrical components, busbars, and waveguides where maximum conductivity is non-negotiable. You’ll also find them in high-vacuum systems, specialty transformers, and a wide array of electronics. Their reliability makes them the preferred choice for architects and fabricators creating durable, corrosion-resistant architectural elements, ensuring both beauty and longevity in various applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
