Welcome to Maduka Metals, your trusted partner in Abuja for premium metal solutions. We take pride in manufacturing and supplying high-performance Incoloy Bright Bars, crafted to meet the rigorous demands of various industries right here in Nigeria. Our commitment is to provide not just a product, but a reliable component that ensures durability and efficiency for your critical projects, backed by our local expertise and dedication to quality that you can count on.
Incoloy Bright Bars are engineered from a sophisticated nickel-iron-chromium alloy, often enhanced with elements like molybdenum and copper. This composition gives them exceptional strength and an outstanding resistance to corrosion, particularly in high-temperature and highly corrosive environments. They maintain their structural integrity and resist oxidation under extreme stress and heat, making them a fundamentally robust material choice for challenging applications where ordinary steels would quickly fail.
| Dimensions | BS, DIN, EN, AISI, JIS, ASME, ASTM |
|---|---|
| Size of Round Bars | Thickness: 2 milimeter-100 milimeter |
| Surface | Bright, Hot Rolled Pickled, Hairline, Cold Drawn, Sand Blasting Finished, Polished |
| Processing | cutting to 650 milimeter |
| Tolerance | H9, K9, H8, H12, K12, H11, H13, K10, K11, H10, or as per need |
| Finish | centreless ground, Cold (bright) drawn, smooth turned, hot rolled, slit rolled edge, peeled, Rough Turned, hot rolled annealed, Polish, Bright, Centreless Ground, Grinding & Black |
| Method | Cold Drawn, Hot Rolled, Cold Rolled Rod, Forged Round Bars |
| Condition | annealed, Hardened & tempered |
| Density | g/cm3 | 7.94 | |
|---|---|---|---|
| lb/in.3 | 0.287 | ||
| Melting Range | °F | 2475 – 2525 | |
| °C | 1357 – 1385 | ||
| Condition & Size | Tensile Strength | Yield Strength (0.2% Offset) | Elongation | Reduction of Area | Hardness |
|---|---|---|---|---|---|
| MPa, min | MPa, min | %, min | %, min | Rockwell, max | |
| Hot worked, as-hot-worked | 550 | 240 | 25 | … | … |
| Cold-worked and hot-worked, annealed | 515 | 205 | 30 | … | … |
| US Bar | Metric | Japanese | Canadian/ASTM | ||||
|---|---|---|---|---|---|---|---|
| Diam. (Inch) | Bar Size | Diam. (mm) | Bar Size | Diameter (mm) | Bar Size | Diameter (mm2) | Bar Size |
| 0.250 | #2 | 5 | 5 | 6 | 6 | 100 | 10M |
| 0.375 | #3 | 5.5 | 5.5 | 10 | 10 | 200 | 15M |
| 0.500 | #4 | 6 | 6 | 13 | 13 | 300 | 20M |
| 0.625 | #5 | 7 | 7 | 16 | 16 | 500 | 25M |
| 0.750 | #6 | 8 | 8 | 19 | 19 | 700 | 30M |
| 0.875 | #7 | 9 | 9 | 22 | 22 | 1000 | 35M |
| 1.000 | #8 | 10 | 10 | 25 | 25 | 1500 | 45M |
| 1.125 | #9 | 11 | 11 | 29 | 29 | 2500 | 55M |
| 1.250 | #10 | 12 | 12 | 32 | 32 | ||
| 1.375 | #11 | 14 | 14 | 35 | 35 | ||
| 1.500 | #12 | 16 | 16 | 38 | 38 | ||
| 1.625 | #13 | 18 | 18 | 41 | 41 | ||
| 1.750 | #14 | 20 | 20 | 44 | 44 | ||
| 1.875 | #15 | 22 | 22 | 48 | 48 | ||
| 2.000 | #16 | 25 | 25 | 51 | 51 | ||
| 2.250 | #18 | 28 | 28 | 57 | 57 | ||
| 32 | 32 | ||||||
| 36 | 36 | ||||||
| 40 | 40 | ||||||
| 44 | 44 | ||||||
| 50 | 50 | ||||||
| Size | kilogram / Meter | kilogram / Foot | Size | kilogram / Meter | kilogram / Foot | Size | kilogram / Meter | kilogram / Foot |
|---|---|---|---|---|---|---|---|---|
| 1/8″ | 0.062 | 0.019 | 22mm | 2.979 | 0.908 | 3-1/4″ | 41.996 | 12.800 |
| 3mm | 0.055 | 0.017 | 20mm | 2.470 | 0.753 | 3″ | 35.762 | 10.900 |
| 4mm | 0.098 | 0.030 | 24mm | 3.543 | 1.080 | 3-3/4″ | 55.780 | 17.001 |
| 5/32″ | 0.095 | 0.029 | 7/8″ | 3.038 | 0.926 | 3-1/2″ | 48.772 | 14.850 |
| 5mm | 0.154 | 0.047 | 1″ | 3.970 | 1.210 | 4-1/4″ | 72.249 | 21.908 |
| 3/16″ | 0.141 | 0.043 | 25mm | 3.871 | 1.180 | 4″ | 63.340 | 19.306 |
| 6mm | 0.223 | 0.068 | 27mm | 4.490 | 1.368 | 4-3/4″ | 90.249 | 27.366 |
| 7/32″ | 0.190 | 0.058 | 26mm | 4.170 | 1.271 | 4-1/2″ | 80.340 | 24.4487 |
| 7mm | 0.298 | 0.091 | 30mm | 5.548 | 1.691 | 5-1/2″ | 121.000 | 36.690 |
| 1/4″ | 0.249 | 0.076 | 1-1/8″ | 5.033 | 1.534 | 5″ | 99.940 | 30.461 |
| 8mm | 0.398 | 0.120 | 32mm | 6.314 | 1.894 | 6-1/2″ | 167.630 | 51.093 |
| 5/16″ | 0.387 | 0.118 | 1-1/4″ | 6.349 | 1.924 | 6″ | 143.900 | 43.860 |
| 3/8″ | 0.557 | 0.170 | 35mm | 7.553 | 2.390 | 7-1/2″ | 225.000 | 68.226 |
| 9mm | 0.498 | 0.152 | 1-3/8″ | 7.550 | 2.303 | 7″ | 196.000 | 59.432 |
| 11mm | 0.748 | 0.228 | 38mm | 8.903 | 2.792 | 10″ | 397.140 | 121.048 |
| 10mm | 0.620 | 0.189 | 36mm | 7.999 | 2.438 | 8″ | 254.55 | 77.586 |
| 12mm | 0.889 | 0.271 | 40mm | 9.872 | 3.009 | |||
| 7/16″ | 0.761 | 0.232 | 1-1/2″ | 8.951 | 2.715 | |||
| 13mm | 1.043 | 0.318 | 1-3/4″ | 12.179 | 3.712 | |||
| 1/2″ | 0.994 | 0.303 | 1-5/8″ | 10.449 | 3.200 | |||
| 9/16″ | 1.256 | 0.383 | 1-7/8″ | 13.977 | 4.260 | |||
| 14mm | 1.207 | 0.368 | 45mm | 12.555 | 3.807 | |||
| 5/8″ | 1.551 | 0.473 | 50mm | 15.414 | 4.698 | |||
| 15mm | 1.391 | 0.424 | 48mm | 14.205 | 4.330 | |||
| 17mm | 1.791 | 0.543 | 2-1/8″ | 17.963 | 5.475 | |||
| 16mm | 1.578 | 0.481 | 2″ | 15.906 | 4.848 | |||
| 18mm | 2.001 | 0.610 | 60mm | 22.205 | 6.768 | |||
| 11/16″ | 1.880 | 0.573 | 2-1/4″ | 20.128 | 6.135 | |||
| 3/4″ | 2.237 | 0.682 | 2-3/8″ | 22.435 | 6.838 | |||
| 2-1/2″ | 24.856 | 7.576 | ||||||
| 2-5/8″ | 27.409 | 8.354 | ||||||
| 2-3/4″ | 30.083 | 9.169 | – | – | – |
Incoloy bright bars offer excellent corrosion resistance, high-temperature strength, durability, oxidation resistance, and versatility in extreme environments.
Incoloy bright bars generally have excellent corrosion resistance due to their alloy composition, reducing the need for additional protective coatings. However, in highly aggressive environments, extra coatings or surface treatments may be applied for enhanced protection.
You will find these bright bars hard at work in some of the most demanding sectors. They are essential in chemical processing plants for constructing reactors and heat exchangers, and in the oil and gas industry for down-hole components and wellhead parts. Their reliability also makes them ideal for power generation equipment, marine engineering, and pollution control systems, proving invaluable wherever strength and resistance to aggressive chemicals and high temperatures are non-negotiable for long-term success.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Maduka Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Abuja, Nigeria
