Welcome to Maduka Metals, your trusted partner in Abuja for high-performance industrial materials. We specialize in supplying and manufacturing Duplex Steel S32205 forgings, providing local industries with robust components that stand up to the most demanding environments. Our commitment is to deliver not just superior products, but also reliable service and expert support, ensuring your projects benefit from the exceptional strength and corrosion resistance that our forgings offer right here in Nigeria.
The composition of Duplex Steel S32205 is a careful balance, blending chromium, nickel, molybdenum, and nitrogen. This synergy gives the forgings outstanding mechanical properties, including very high tensile and yield strength, along with good toughness. This combination means components can handle significant stress and pressure without sacrificing their structural integrity, making them far more resilient than standard stainless steels across a wide range of challenging conditions.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32205 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
| STANDARD | WERKSTOFF NR. | UNS | SAF |
| Duplex Steel S32205 | 1.4462 | S32205 | 2205 |
Duplex Steel S32205 forgings are available in various sizes, including round, square, and custom shapes. They can range from small to large diameters and lengths, depending on application requirements.
Yes, S32205 Duplex Steel forgings are highly resistant to corrosion, particularly in chloride-rich environments. They offer excellent resistance to pitting, crevice, and stress corrosion cracking, making them ideal for harsh conditions.
The maximum operating temperature for Duplex Steel S32205 forgings is typically around 300°C (572°F). Beyond this, the material's strength and corrosion resistance may degrade due to sensitization and phase changes.
Thanks to their unique blend of strength and corrosion resistance, these forgings are invaluable across many sectors. They are essential in the oil and gas industry for critical components like valves and pump shafts, and in chemical processing plants where they resist aggressive acids. You’ll also find them in demanding marine environments and in the construction of heavy machinery, proving their reliability wherever durability and long service life are non-negotiable.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Maduka Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Abuja, Nigeria
