Welcome to Maduka Metals, your trusted partner in Abuja for high-performance nickel alloys. We take pride in manufacturing and supplying superior Inconel 600 forgings, crafted to meet the rigorous demands of various industries right here in Nigeria. Our commitment is to deliver components that offer exceptional reliability and longevity, ensuring your projects are built on a foundation of quality and strength you can count on for even the most challenging applications.
Inconel 600 is primarily composed of nickel, chromium, and iron, giving it a remarkable balance of strength and resistance. This alloy maintains excellent mechanical properties even under intense heat, offering high tensile strength and outstanding resistance to oxidation. It also performs exceptionally well in corrosive environments, resisting chloride stress-corrosion cracking, which makes it a durable and long-lasting material choice for critical components.
Specifications ASTM B564 / ASME SB564, AMS 5766
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015 max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.47 g/cm3 | 1413 °C (2580 °F) | 655 MPa, 95000 psi | 310 MPa, 45000 psi | 45 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Alloy 600 | N06600 | 2.4816 | NC15FE11M | NiCr15Fe | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | ЭИ868 |
The forging process for Inconel 600 typically takes several hours, depending on the complexity and size of the component. Heating, shaping, and cooling are carefully controlled to ensure the desired mechanical properties.
Post-forging operations for Inconel 600 typically include heat treatment to relieve stresses and enhance mechanical properties. Additional processes like machining, surface finishing, and testing may also be required to meet specific application standards.
Inconel 600 forgings require minimal maintenance due to their excellent corrosion and oxidation resistance. Periodic inspection for signs of wear, cracking, or thermal damage is recommended to ensure long-term performance in demanding environments.
The uses for our Inconel 600 forgings are extensive, particularly in sectors where failure is not an option. They are essential in chemical processing plants for handling caustic solutions, in aerospace for turbine components and heat-treating fixtures, and in the power generation industry for nuclear reactor parts. From furnace systems to pollution control equipment, these forgings provide the necessary resilience to withstand extreme temperatures and corrosive conditions, ensuring operational safety and efficiency.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Maduka Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Abuja, Nigeria
