Maduka Metals, located in Abuja, Nigeria, stands out as a top manufacturer and supplier of **Stainless Steel 904L Hollow Bars**. We pride ourselves on delivering exceptional quality and durability for a wide range of industrial applications. Our 904L Hollow Bars are made from high-grade raw materials and cutting-edge production methods, ensuring they resist corrosion, pitting, and stress cracking like champions. With their remarkable formability and weldability, these bars are perfect for even the toughest environments. At Maduka Metals, we are dedicated to providing high-performance stainless steel products that not only meet international standards but also adapt to the changing needs of our clients across various industries.
Stainless Steel 904L Hollow Bars boast a rich composition that includes significant amounts of chromium, nickel, molybdenum, and copper, which greatly enhance their resistance to corrosion in acidic and chloride-rich settings. Typically, you’ll find 19–23% chromium, 23–28% nickel, 4–5% molybdenum, and 1–2% copper in these bars. They exhibit impressive mechanical properties, with a tensile strength ranging from 490–710 MPa, a yield strength of 220 MPa, and excellent elongation characteristics. With a hardness of about 70 HRB, 904L showcases remarkable toughness, ductility, and oxidation resistance, even when the heat is on, making it perfect for demanding applications.
| Standard | ASTM B649, ASME SB649 |
| Round Bar Size | 3mm~ 800mm |
| Square Bar Size | 4mm* 4mm ~100mm* 100mm |
| Flat Bar Size | 2mm ~ 100mm |
| Hex Bar Size | 2mm ~ 100mm |
| Angle Size | 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm |
| Thickness | 50 mm to 6000 mm Long |
| Length | 1 To 6 Meters, Custom Cut Length |
| Form | Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc |
| Grade | Ni | Mo | Cr | Cu | C | Mn | Si | P | S |
| 904L | 23 – 28 | 4 – 5 | 19 – 23 | 1 – 2 | 0.02 max | 2.0 max | 1.0 max | 0.045 max | 0.035 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.05 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | AFNOR | JIS | BS | KS | EN |
| 904L | 1.4539 | N08904 | Z2NCUD31-20AZ | SUS 890L | 904S13 | STS 317J5L | X1NiCrMoCu25-20-5 |
SS 904L stainless steel consists of approximately 24-26% chromium, 19-23% nickel, 4-5% molybdenum, 1-2% copper, and small amounts of manganese, silicon, and carbon. The copper enhances corrosion resistance, particularly in acidic environments, while maintaining high strength.
The typical diameter range for SS 904L hollow bars varies from 10 mm to 300 mm, although custom sizes can be manufactured. These bars are available in various wall thicknesses, depending on specific application requirements and industry standards.
Stainless Steel 904L Hollow Bars are a go-to choice in industries that demand top-notch corrosion resistance and durability. You’ll find them in chemical processing plants, marine settings, and oil and gas refineries. These bars are also utilized in heat exchangers, pulp and paper machinery, condenser tubes, and pollution control systems. Plus, they’re well-suited for architectural structures, pharmaceutical equipment, and desalination plants. Thanks to their outstanding strength, weldability, and resistance to harsh chemicals, they’re an ideal fit for both structural and process engineering projects.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
