Maduka Metals, a reputable manufacturer and supplier located in Abuja, Nigeria, focuses on crafting top-notch Stainless Steel XM19 Forgings that are designed for outstanding strength, resistance to corrosion, and long-lasting durability. These forgings are made to comply with international standards, guaranteeing dependable performance even in tough industrial, marine, and chemical settings. Maduka Metals caters to a diverse array of industries, including aerospace, petrochemical, marine, and power generation, offering cutting-edge stainless steel solutions. Thanks to precise forging techniques and rigorous quality control, each Stainless Steel XM19 Forging boasts remarkable mechanical properties, long-term stability, and resistance to pitting, stress corrosion, and oxidation, making them perfect for high-performance applications that demand reliability.
Stainless Steel XM19 Forgings are crafted from a high-performance martensitic stainless steel alloy, which contains around 17–19% chromium, 7–10% nickel, 2–3% molybdenum, along with trace amounts of copper, manganese, and carbon. This unique blend provides exceptional resistance to corrosion, impressive tensile strength, and excellent toughness. In terms of mechanics, XM19 showcases a tensile strength ranging from 950–1200 MPa, yield strength between 750–900 MPa, and hardness levels of 28–34 HRC. Its combination of mechanical strength, corrosion resistance, and fatigue resistance makes it a top choice for critical applications in industrial, marine, and aerospace sectors.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
| SS XM19 | 0.06 max | 0.10 max | 0.1 max | – | 0.03 max | 20.50 – 23.50 | – | 11.50 – 13.50 |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| ksi – 95 | ksi – 50 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS XM19 | 1.3964 | S20910 |
The forging process for Stainless Steel XM19 typically takes several hours, depending on the size and complexity of the part. Heating, shaping, and cooling stages contribute to the overall duration.
The ideal temperature range for forging Stainless Steel XM19 is between 2100°F to 2200°F (1149°C to 1204°C). It's important to maintain proper cooling to avoid distortion or cracking.
Yes, Stainless Steel XM19 (a high-strength alloy) can be forged into custom shapes. It offers excellent formability, allowing manufacturers to create parts with specific dimensions and designs as needed.
Stainless Steel XM19 Forgings find extensive use in industries that require components to be high-strength, corrosion-resistant, and durable. In marine settings, they are utilized for shafts, fasteners, and structural elements that are exposed to seawater and environments rich in chlorides. The aerospace and petrochemical sectors rely on XM19 forgings for turbine components, valves, and parts of machinery that endure high stress. In chemical processing, they are perfect for reactors, pumps, and piping systems that handle corrosive fluids. Furthermore, Stainless Steel XM19 Forgings are also well-suited for power generation and industrial machinery applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
