Maduka Metals, a reputable manufacturer and supplier located in Abuja, Nigeria, focuses on producing top-notch Titanium Grade 1 Bars and Rods. These products are celebrated for their remarkable corrosion resistance, ductility, and durability. Crafted to meet international standards, they promise reliable performance even in the most demanding industrial and engineering settings. Maduka Metals caters to a diverse range of sectors, including chemical processing, marine, aerospace, and medical industries, offering exceptional titanium solutions. Thanks to advanced production methods and rigorous quality control, each Titanium Grade 1 Bar and Rod boasts impressive mechanical properties, a long service life, and resilience in tough environments, making them perfect for critical structural and industrial applications.
Titanium Grade 1 Bars and Rods are made from commercially pure titanium, featuring minimal trace elements like oxygen, nitrogen, carbon, and iron to boost strength while maintaining corrosion resistance. On the mechanical side, Grade 1 titanium shows a tensile strength of about 240–345 MPa and an elongation of 24–36%, which translates to outstanding ductility and toughness. Its low density, excellent chemical stability, and resistance to both oxidizing and reducing environments make it a great fit for a variety of structural, industrial, and specialized applications that demand long-term reliability.
| Standards : | ASTM B348, B863 / ASME SB 348, SB 863 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr 1 | 3.7025 | R50250 |
| Grade | C | N | O | H | Ti | Fe |
| Titanium Grade 1 | 0.08 max | 0.03 max | 0.18 max | 0.015 max | Bal | 0.20 20 |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 240 | 170 | 24 % |
| Physical Properties | Metric | English |
|---|---|---|
| Density | 4.51 g/cc | 0.163 lb/in³ |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Titanium Grade 1 Bars Standard lengths of 2000 mm up to 6000 mm. Cut to size on request (tolerance +2/-0 mm).
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@www.madukametal.com
These Titanium Grade 1 Bars and Rods find extensive use in industries that prioritize high corrosion resistance, strength, and biocompatibility. In the chemical and petrochemical fields, they are utilized in piping systems, heat exchangers, and storage tanks that come into contact with aggressive chemicals. The marine sector relies on them for ship components, offshore structures, and desalination plants, thanks to their ability to withstand saltwater corrosion. In the medical field, they are perfect for surgical instruments and implants. Moreover, Titanium Grade 1 Bars and Rods are also employed in aerospace, automotive, and power generation applications where durability, reliability, and performance are crucial.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
