Maduka Metals, a prominent manufacturer and supplier located in Abuja, Nigeria, specializes in top-notch Titanium Grade 12 Bars and Rods, designed for exceptional corrosion resistance, strength, and durability. These products are crafted to meet international standards, guaranteeing reliable performance even in tough industrial settings. Maduka Metals serves a variety of industries, including chemical processing, aerospace, marine, and power generation, providing high-performance titanium solutions. With cutting-edge manufacturing technology and rigorous quality control, each Titanium Grade 12 Bar and Rod boasts outstanding mechanical properties, a long service life, and resistance to harsh environments, making them perfect for critical applications in demanding fields.
Titanium Grade 12 Bars and Rods are made from titanium alloyed with 0.3% molybdenum, 0.8% nickel, and trace amounts of iron and other elements. This special blend offers remarkable corrosion resistance, especially in both oxidizing and reducing environments, while still maintaining impressive strength. Mechanically, Grade 12 titanium has a tensile strength of around 620–750 MPa and an elongation of 20–25%, providing a well-rounded mix of toughness, fatigue resistance, and dimensional stability. Its lightweight nature and ability to endure extreme chemical and thermal conditions make it ideal for high-performance industrial uses.
| Standards : | ASTM B348, B863 / ASME SB348, SB863 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 12 | 3.7105 | R53400 |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 9 | .08 max | .03 max | .25 max | .015 max | Bal | 0.30 max | – | .12 – .25 |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade 12 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Density | Melting Range | Modulus of Elasticity (Tension) | Specific Heat | Mean Coefficient of Expansion | Thermal conductivity | Electrical Resistivity |
| kg/m3 | °C | GPa | J/kg. °C | x10 -6 / °C | W / m. °C | micro-ohm.m |
| 4,507 | 1668± 10 | 103 | 519 | 8.41 | 11.4 | 0.420 |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Grade 12 Titanium Bars Standard lengths of 2000 mm up to 6000 mm. Cut to size on request (tolerance +2/-0 mm).
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
Titanium Grade 12 offers excellent resistance to corrosion, especially in oxidizing and mildly reducing environments, and is highly durable in seawater and chemical processing conditions.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@www.madukametal.com
Yes, Titanium Grade 12 exhibits remarkable high-temperature resistance, making it suitable for use in power generation and industrial processes that involve elevated temperatures.
These Titanium Grade 12 Bars and Rods find extensive application in industries that demand corrosion-resistant and high-strength materials. In the chemical and petrochemical sectors, they are utilized for heat exchangers, piping, and storage tanks that come into contact with aggressive chemicals. The marine industry uses them in desalination plants, ship components, and offshore structures. In aerospace and power generation, they serve as structural components and equipment that require long-lasting durability. Furthermore, Titanium Grade 12 Bars and Rods are also suitable for medical, industrial, and engineering applications where reliability is crucial.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
