Maduka Metals, a reputable manufacturer and supplier located in Abuja, Nigeria, is all about crafting top-notch Titanium Grade 11 Forgings. Known for their exceptional corrosion resistance and mechanical strength, these forgings are designed to meet the rigorous demands of various industries. With a keen emphasis on precision engineering and quality control, Maduka Metals guarantees that every Titanium Gr 11 forging performs excellently, showcasing durability and reliability. Thanks to their cutting-edge facilities and unwavering commitment to quality, they’ve become the go-to choice for clients in need of trustworthy titanium solutions for chemical processing, marine, and aerospace sectors.
Titanium Grade 11 Forgings mainly consist of titanium with a touch of palladium, which boosts their corrosion resistance, especially in reducing and mildly oxidizing environments. They boast impressive ductility, weldability, and toughness, with a tensile strength ranging from 275 to 450 MPa and a density of 4.51 g/cm³. These forgings are highly resistant to crevice and pitting corrosion, maintaining stability in seawater and chloride environments, making them perfect for long-term use in challenging chemical and marine settings.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 11 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | 12 – .25 |
| Grade | Tensile Strength min | Yield Strength (0.2 % Offset) | Elongation | Reduction of Area | ||
| ksi | Mpa | ksi | Mpa | min % | min % | |
| 11 | 35 | 240 | 25 | 170 | 24 | 30 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 11 | 3.7225 | R52550 |
Yes, Titanium Gr 11 forgings are highly corrosion-resistant, especially to oxidizing environments and seawater. This makes them ideal for applications in industries like aerospace, marine, and chemical processing, ensuring long-lasting durability.
Titanium Gr 11 forgings are commonly used in industries such as aerospace, marine, chemical processing, medical, and power generation. Their strength, corrosion resistance, and high-performance capabilities make them ideal for demanding applications.
Yes, Titanium Gr 11 forgings can be customized for specific applications, offering tailored sizes, shapes, and properties to meet unique industry requirements, ensuring optimal performance and reliability in demanding environments.
You’ll find Titanium Grade 11 Forgings widely utilized in industries that require outstanding corrosion resistance and structural integrity. They’re commonly found in chemical processing equipment, heat exchangers, marine hardware, and desalination systems. Their excellent weldability and formability make them ideal for creating pressure vessels, piping systems, and reactor components. In the aerospace and power generation fields, these forgings are prized for their impressive strength-to-weight ratio and resistance to corrosive fluids, ensuring reliable performance even in extreme operational conditions and extending their service life in demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
