Maduka Metals, a reputable manufacturer and supplier located in Abuja, Nigeria, is known for its top-notch Titanium Grade 2 Forgings. These forgings are celebrated for their remarkable corrosion resistance, strength, and durability. Crafted to meet international standards, they promise reliable performance even in the toughest industrial and engineering settings. Maduka Metals caters to a diverse array of industries, including chemical processing, aerospace, marine, and power generation, offering exceptional titanium solutions. Thanks to cutting-edge forging technology and rigorous quality control, each Titanium Grade 2 Forging boasts impressive mechanical properties, a long service life, and the ability to withstand harsh environments, making them perfect for critical structural and high-performance applications.
Titanium Grade 2 Forgings are made from commercially pure titanium, with small amounts of oxygen, nitrogen, carbon, and iron added to boost strength while keeping corrosion resistance at an exceptional level. In terms of mechanics, Grade 2 titanium has a tensile strength ranging from about 345 to 450 MPa and an elongation of 20 to 25%, which translates to excellent toughness, ductility, and fatigue resistance. Its lightweight nature, high chemical stability, and capacity to endure extreme industrial and marine conditions make it a go-to choice for structural, chemical, and high-performance engineering applications, ensuring both durability and long-lasting reliability.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| ASTM B381 R50400 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 2 | 3.7035 | R50400 |
The durability of Titanium Gr 2 forgings is ensured by factors like high corrosion resistance, excellent strength-to-weight ratio, superior fatigue resistance, heat treatment, proper alloy composition, and precision manufacturing processes.
Titanium Gr 2 forgings are commonly used in aerospace, chemical processing, marine, medical, automotive, and power generation industries due to their corrosion resistance, strength, and lightweight properties.
Open-die forging for Titanium Gr 2 components involves shaping the metal by pressing it between two flat dies. It allows for high strength, uniformity, and precise control, making it ideal for complex, large components.
These Titanium Grade 2 Forgings find their place in industries that demand high corrosion resistance, strength, and reliability. In the chemical and petrochemical sectors, they are utilized for reactors, heat exchangers, piping systems, and storage tanks that come into contact with aggressive chemicals. The marine industry relies on them for ship components, offshore structures, and desalination plants, thanks to their outstanding resistance to saltwater corrosion. In aerospace and power generation, these forgings are essential for structural components and critical equipment. Moreover, Titanium Grade 2 Forgings are also well-suited for medical, industrial, and engineering applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Maduka Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Abuja, Nigeria
